LAS5035, LAS5040, LAS5045, LAS5050 + LAS5055 Brush Seals
Face-fixed
Hard wearing brush seals, suitable for numerous installations and door types. Nylon brush seals with aluminium carriers. Flexible and durable. Quick and easy installation.
Finish
System specification
| Property | LAS5035 | LAS5040 | LAS5045 | LAS5050 | LAS5055 |
|---|---|---|---|---|---|
| LOCATION | Head, jambs, threshold + meeting stiles of single + double swing doors, + sliding doors. Head, jambs + threshold of revolving doors, up + over doors, + roller shutter doors | Head, jambs, threshold + meeting stiles of single + double swing doors, + sliding doors. Head, jambs + threshold of revolving doors, up + over doors, + roller shutter doors | Head, jambs, threshold + meeting stiles of single + double swing doors, + sliding doors. Head, jambs + threshold of revolving doors, up + over doors, + roller shutter doors | Head, jambs, threshold + meeting stiles of single + double swing doors, + sliding doors. Head, jambs + threshold of revolving doors, up + over doors, + roller shutter doors | Head, jambs, threshold + meeting stiles of single + double swing doors, + sliding doors. Head, jambs + threshold of revolving doors, up + over doors, + roller shutter doors |
| MIN/MAX GAP SIZES | 20mm/40mm | 40mm/60mm | 60mm/80mm | 80mm/120mm | 120mm/150mm |
| SEAL MATERIAL | Polypropylene brush filaments, UV stabilised | Polypropylene brush filaments, UV stabilised | Polypropylene brush filaments, UV stabilised | Polypropylene brush filaments, UV stabilised | Polypropylene brush filaments, UV stabilised |
| Standard finish | Silver anodised aluminium with black brush filaments | Silver anodised aluminium with black brush filaments | Silver anodised aluminium with black brush filaments | Silver anodised aluminium with black brush filaments | Silver anodised aluminium with black brush filaments |
| Non-standard finish | Bronze anodised aluminium with black brush filaments are subject to non-standard charges and additional lead times | Bronze anodised aluminium with black brush filaments are subject to non-standard charges and additional lead times | Bronze anodised aluminium with black brush filaments are subject to non-standard charges and additional lead times | Bronze anodised aluminium with black brush filaments are subject to non-standard charges and additional lead times | Bronze anodised aluminium with black brush filaments are subject to non-standard charges and additional lead times |
| STANDARD LENGTHS | 1m + 2.1m. Other lengths to special order | 1m + 2.1m. Other lengths to special order | 1m + 2.1m. Other lengths to special order | 1m + 2.1m. Other lengths to special order | 1m + 2.1m. Other lengths to special order |
